钻机能力

Drilling capacity

钻深Drilling depth

200m

钻孔(钻头)直径

Borehole (Drill bit) dia.

?115～?350mm

给进系统

Feeding system

提升力Lifting capacity

16 Ton

推进力Thrusting capacity

8 Ton

动力头参数

Drive head

回转转速Rotary speed

60~140 r/min

扭矩     Torque

4000~2000N.m

动力部分

Power Unit

柴油机型号Engine Model

Yunnei engine YN33GB

额定功率/转速

Rated power/speed

58kW/ 2400r/min

工具卷扬Tool winch capacity

0.9 Ton

配套钻杆

Drill pipe

钻杆直径Drill pipe dia.

?76/ ?89mm

钻杆长度Drill pipe length

3000mm

配套空压机             Air compressor

耗气总量Air consumption

16～35m3/min

工作风压Air pressure

10.5～24.6bar

履带参数

Crawler chassis

行走速度Walking speed

0～3 km/h

爬坡能力Climbing angle

Max. 25°

整机尺寸

Dimension

运输状态Transport

3400*1700*2300mm

工作状态Working

3400*2500*6500mm

整机重量Weight

4000kg
